CW-Electric Winch
Model No : F500
F500 MINI CRANE WITH WINCH
F500 Mini Crane with Winch is a compact and reliable lifting machine designed for efficient material handling and construction applications. With a lifting capacity of 150–200kg, it delivers smooth hoisting performance using a durable galvanized wire rope and powerful motor system. Available with clutch and non-clutch variants, this crane offers stable operation, easy handling, and improved productivity for various industrial and site requirements.
Technical Specification
| Load Capacity | 150-200kg |
| Wire Rope Length | 30m (Galvanized) |
| Wire Diameter | 7mm |
| Motor Power | 3kW |
| Voltage Hoisting | 220V / 440V |
| Speed | 15m/min |
| Weight | 40kg |
| Variants 1 | CW350 With Clutch |
| Variants 2 | CW525 Without Clutch |
